4/6/8/10/12 Circuit electrical enclosure

Intro Product Category：lighting box

Address：No. 607, wanweng Road, Weng Long Street Industrial Zone

Tel：0557-57151737

<< >>

4/6/8/10/12 Circuit electrical enclosure
4/6/8/10/12 Circuit electrical enclosure
4/6/8/10/12 Circuit electrical enclosure
4/6/8/10/12 Circuit electrical enclosure

Detail
Relate Products

Detail

Specifications			Box size			Panel size
Specifications			height	width	depth	height	width
DH PZ30 R4	hide	4	145	155	79	175	165
DH PZ30 R6	hide	6	175	220	89	195	240
DH PZ30 R8	hide	8	210	220	89	230	240
DH PZ30 R10	hide	10	250	220	89	270	240
DH PZ30 R12	hide	12	285	220	89	305	240
DH PZ30 R15	hide	15	340	220	89	260	240
DH PZ30 R18	hide	18	395	220	89	415	240
DH PZ30 R20	hide	20 (Single line)	425	220	89	445	240
DH PZ30 R20	hide	20 (Double row)	250	430	89	270	450
DH PZ30 R24	hide	24 (Double row)	285	430	89	305	450
DH PZ30 R30	hide	30 (Double row)	340	430	89	360	450
DH PZ30 R36	hide	36 (Double row)	395	430	89	415	450
DH PZ30 R45	hide	45 (Three lines)	340	600	89	360	620
In millimeters
