4-36 way three-phase iron or stainless steel wall monted enclosure distribution box
Intro Product Category：lighting box

Address：No. 607, wanweng Road, Weng Long Street Industrial Zone

Tel：0557-57151737

<< >>

  • 4-36 way three-phase iron or stainless steel wall monted enclosure distribution box

  • 4-36 way three-phase iron or stainless steel wall monted enclosure distribution box

  • 4-36 way three-phase iron or stainless steel wall monted enclosure distribution box

  • Detail
  • Relate Products
Detail
Specifications Box size Panel size
height width depth height width
DH PZ30 M4 Surface mounting 4 165 175 79 175 165
DH PZ30 M6 Surface mounting 6 195 240 89 195 240
DH PZ30 M8 Surface mounting 8 230 240 89 230 240
DH PZ30 M10 Surface mounting 10 270 240 89 270 240
DH PZ30 M12 Surface mounting 12 305 240 89 305 240
DH PZ30 M15 Surface mounting 15 360 240 89 260 240
DH PZ30 M18 Surface mounting 18 415 240 89 415 240
DH PZ30 M20 Surface mounting 20 (Single line) 445 240 89 445 240
DH PZ30 M20 Surface mounting 20 (Double row) 270 450 89 270 450
DH PZ30 M24 Surface mounting 24 (Double row) 305 450 89 305 450
DH PZ30 M30 Surface mounting 30 (Double row) 360 430 89 360 450
DH PZ30 M36 Surface mounting 36 (Double row) 415 450 89 415 450
DH PZ30 M45 Surface mounting 45 (Three lines) 340 620 89 360 620
In millimeters
