15kv shielded rear connector
Short Description:
15kv shielded rear connector:The shielded rear connector is used in cable branch boxes, ring main units, and box transformers, ensuring that the product can achieve multi-branch power supply. It is used for fully sealed connections with Φ46/Φ56/91.5/M16 bushings and is suitable for 8.7/15kV, 12/20kV …
Product details
15kv shielded rear connector:
The shielded rear connector is used in cable branch boxes, ring main units, and box transformers, ensuring that the product can achieve multi-branch power supply. It is used for fully sealed connections with Φ46/Φ56/91.5/M16 bushings and is suitable for 8.7/15kV, 12/20kV cross-linked cables with cable cross-sections ranging from 25 to 500mm^2.
Product Features:
It can better handle the electric field intensity at the cable fracture, with superior electrical performance. With a small space, the structural design is reasonable, easy to install, and has higher tolerance.
