DFW European style cable distribution box
Short Description:
European-style cable tap box is widely used in cable engineering equipment in power distribution network system in recent years.
Product details
Product overview
European-style cable tap box is widely used in cable engineering equipment in power distribution network system in recent years. Its main features are bidirectional door opening, using butt-joint sleeve as connecting busbar, and it has obvious advantages such as small length, clear cable arrangement, no need for large span crossing of three-core cables, etc. The cable joints adopted conform to DIN47636 standard.
Generally, the rated current 630A bolt is used to fix the connected cable connector.
Normal operating environment
Ambient temperature: maximum temperature: +40℃ , minimum temperature -30℃
Wind speed: equivalent to 34m/s (not more than 700Pa)
Humidity: the average daily relative humidity is not more than 95%, and the average monthly relative humidity is not more than 90%
Earthquake prevention: horizontal acceleration is not more than 0.4m/s2
, vertical acceleration is not more than 0.1 5m/s2
Inclination of installation site: no more than 3°
Installation environment: ambient air shall be free from obvious pollution such as corrosiveness, combustible gas and water vapor, and the installation
site shall be free from violent vibration.
Please consult with our company when ordering this product beyond the above conditions.
