KYN61-40.5 (Z) Armored Removable AC Metal Enclosed Switchgear
Short Description:
KYN61-40.5(Z) Armored Removable AC Metal Enclosed Switchgear (hereinafter referred to as Switchgear) is a three-phase AC 50Hz indoor complete power distribution device with a rated voltage of 40.5kV.
Product details
Product overview
KYN61-40.5(Z) Armored Removable AC Metal Enclosed Switchgear (hereinafter referred to as Switchgear) is a three-phase AC 50Hz indoor complete power distribution device with a rated voltage of 40.5kV. As power plants, substations and industrial and mining enterprises to receive and distribute electricity. It can control, protect and detect circuits, and can also be used in places with frequent operations.
This switch cabinet complies with GB/T11022-1999, GB3906-1991, DL404-1997 and other standards.
Normal operating environment
◇ The cabinet body structure adopts assembly type, and the circuit breaker adopts handcart floor type structure;
◇ Equipped with brand-new composite insulated vacuum circuit breaker, with good interchangeability and easy replacement.
◇ The frame of the handcart is equipped with a screw and nut propulsion mechanism, which can easily move the handcart and prevent misoperation from damaging the propulsion structure;
◇ All operations can be performed when the cabinet door is closed;
◇ The interlock between the main switch, handcart and switch cabinet door adopts mandatory mechanical locking to meet the "five prevention" function;
◇ Cable room has plenty of space and can connect multiple cables;
◇ Quick grounding switch is used for grounding and short circuit of circuit;
◇ The protection level of the shell is IP3X, and the protection level is IP2X when the handcart door is open;
◇ The product conforms to GB3906-1991, DL404-1997 and adopts international IEC-298 standard by reference.
