XGN15-12 Box type Fixed AC Metal Enclosed Switchgear
Short Description:
XGN15-12 Unit AC Metal Closed Loop Network Switching Equipment (hereinafter referred to as Ring Network Cabinet) is a new generation of highvoltage electrical appliances that we have successfully designed and developed by ourselves in accordance with the requirements of domestic rural power and city network reconstruction after introducing advanced foreign technologies. All technical performance indexes comply with IEC62271- 200:2003 and GB3906 standards.
Product details
Product overview
XGN15-12 Unit AC Metal Closed Loop Network Switching Equipment (hereinafter referred to as Ring Network Cabinet) is a new generation of highvoltage electrical appliances that we have successfully designed and developed by ourselves in accordance with the requirements of domestic rural power and city network reconstruction after introducing advanced foreign technologies. All technical performance indexes comply with IEC62271- 200:2003 and GB3906 standards.
The main switch, operating mechanism and components of the ring network cabinet adopt original equipment or SFL-12/24 switching equipment assembled and produced in China with imported components, and can also be equipped with original HAD/ US SF6 according to user requirements. Circuit breaker or VD4-S type vacuum circuit breaker. Its operation mode is divided into dynamic and electric.
The cabinet body is riveted after being processed by a numerical control machine tool, the protection level reaches IP3X, and reliable mechanical interlocking and misoperation prevention functions are provided. This product is characterized by small volume, light weight, beautiful appearance, simple operation, long service life, high parameters, no pollution, little maintenance, etc.
XGN15-12 Type Unit AC Metal Closed Loop Network Switching Equipment is applicable to AC 50Hz and 12kV power networks for receiving and distributing electric energy. The main switch in the cabinet is SF6 switch.
