XGN15-12 box-type fixed AC metal enclosed switchgear
Short Description:
OverviewThe XGN15-12 series AC metal ring main switchgear is a compact, scalable, metal enclosed ring main switchgear suitable for distribution automation. It utilizes the FLN □ -12 type SF6 load switch as the main switch and employs air insulation throughout the entire cabinet. It features a simple …
Product details
Overview
The XGN15-12 series AC metal ring main switchgear is a compact, scalable, metal enclosed ring main switchgear suitable for distribution automation. It utilizes the FLN □ -12 type SF6 load switch as the main switch and employs air insulation throughout the entire cabinet. It features a simple structure, flexible operation, reliable interlocking, and convenient installation. It can provide technical solutions for various application scenarios and user requirements.
The main switch of the XGN15-12 series AC metal ring main switchgear is either the FLN36-12 type produced by our company or the SFG type SF6 load switch produced by our company. Alternatively, it can be equipped with VS1 type, VD4/S type, ISM type vacuum circuit breakers or HD4/S5 type SF6 circuit breakers according to user needs. The load switch and circuit breaker can be manually or electrically operated. After selecting and equipping with an electric operating mechanism, PT, CT, FTU, and communication devices, the distribution automation function can be realized.
