GW13-40.5
Short Description:
The isolation switch consists of a bracket, base, post insulator, contact, terminal block, and other parts. The post insulators and conductive parts are installed on the base, with an intersection angle of 50 between the two post insulators. The base is fixed on a bracket tilted at 25 degrees.The bracket is equipped with a shaft connected to the operating machine. Can be equipped with CS17-G manual kneading mechanism or CJ6 electric mechanism.
Product details
Overview
The isolation switch consists of a bracket, base, post insulator, contact, terminal block, and other parts. The post insulators and conductive parts are installed on the base, with an intersection angle of 50 between the two post insulators. The base is fixed on a bracket tilted at 25 degrees.The bracket is equipped with a shaft connected to the operating machine. Can be equipped with CS17-G manual kneading mechanism or CJ6 electric mechanism.
Product Features
The isolation switch adopts a double column center opening and contact turning structure, which has the ability to self clean contacts and improves contact reliability;
The rotating part of the isolation switch is designed to be maintenance free. The rotating seat is designed with a sealed structure, which prevents water vapor, dust, and harmful gases from entering,ensuring that the bearings and lithium based grease of molybdenum disulfide always work in a good environment. The shaft spine does not rust, the grease cannot be lost, and it never dries,so that the rubbing torque of the isolation switch wil not increase after long-term operation. Adopting a structure that combines stainless steel shaft pins with oil-free self-lubricating shaft supports; The steel components are hot-dip galvanized to ensure flexible, lightweight, reliable, and rust free operation of the isolation switch.
