Low Voltage Reactive Power Intelligent Compensation Device GGJ
Short Description:
Product OverviewThe GGJ low-voltage reactive power intelligent compensation device adopts computer-aided design (CAD), introduces microcomputer control, and implements intelligent tracking compensation for reactive power. Its structure is reasonable, technology is advanced, and it is widely used in …
Product details
Product Overview
The GGJ low-voltage reactive power intelligent compensation device adopts computer-aided design (CAD), introduces microcomputer control, and implements intelligent tracking compensation for reactive power. Its structure is reasonable, technology is advanced, and it is widely used in low-voltage power grids to improve power factor, reduce reactive power loss, and improve power supply quality. It is a new generation of energy-saving products. Dedicated to reactive power compensation for 130-600kVA three-phase transformers.
Environmental Conditions for Use
◆ Altitude: ≤ 2000m;
◆ Environmental temperature: -20 ℃ to+45 ℃ ;
◆ Relative humidity: ≤ 90% at 20 ℃ ;
◆ Installation environment: No harmful gases and vapors, no conductive or explosive dust particles, and severe mold.
Main Features
◆ Adopting intelligent controller control, with complete functions, reliable peLXormance, and automatic compensation mode: can increase the power factor to 0.9 or above:
◆ Real time display of grid power factor, display range: lagging (0.00-0.99), leading (0.00-0.99):
◆ It has multiple comprehensive protection functions such as overvoltage, over harmonics, over compensation, system faults, phase loss, overload, etc;
◆ Remember the set parameters, and the system will not lose them after a power outage. After the power grid returns to normal, it will automatically enter the operating state without the need for personnel to be on duty:
◆ According to the load balance of the power grid, split phase compensation or mixed compensation can be adopted;
◆ Strong anti-inteLXerence ability, able to withstand 2000V inteLXerence pulses directly input from the power grid, higher than national professional standards.
Main Technical Parameters
◆ Rated voltage: 0.38-0.66kV;
◆ Rated frequency: 50Hz;
◆ Rated capacity: 1-600kvar;
◆ Applicable voltage range: (0.85-1.1) times the rated voltage;
◆ Maximum allowable current: 1.3 times the rated current;
◆ Control circuit: 1-16 circuits;
◆ Switching time: 1-150S/time, adjustable;
◆ Working mode: automatic, continuous operation.
