XGN66-12(Z) Fixed Enclosed Switchgear
Short Description:
Product OverviewXGN66-12 fixed enclosed switchgear (hereinafter referred to as switchgear) is a new generation of high-voltage electrical equipment products of our company, which meets the requirements of the national standard GB3906 3-35kV AC Metal Enclosed Switchgear and the Ministry of Electric P …
Product details
Product Overview
XGN66-12 fixed enclosed switchgear (hereinafter referred to as switchgear) is a new generation of high-voltage electrical equipment products of our company, which meets the requirements of the national standard GB3906 "3-35kV AC Metal Enclosed Switchgear" and the Ministry of Electric Power DLT404 "Technical Conditions for Ordering Indoor AC High Voltage Switchgear", as well as the international standard IEC60298 "Requirements for AC Metal Enclosed Switchgear and Control Equipment above 1kV and below 52kV".
This product has absorbed advanced foreign technology and is small in size, only 50% of the volume of ordinary switchgear; Circuit breakers have high reliability and good peLXormance; The "five prevention" interlocking mechanism has the advantages of reliability and simplicity. The switchgear is an indoor complete set of 3.6, 7.2, and 12kV three-phase AC 50Hz single busbar segmented devices, used for receiving and distributing electrical energy. It also has functions such as controlling, protecting, and monitoring circuits, and can be used in various types of power plants, substations, industrial and mining enterprises, high-rise buildings, and other places. It can also be combined with ring main cabinets for application in switching stations.
Structural Characteristics
The cabinet body is made of high-quality angle steel welded together.
◇ The circuit breaker room is located in the middle (lower) part of the cabinet, making installation, debugging, and maintenance convenient. The standard VS1 circuit breaker is equipped with a pressure release channel to ensure personal safety.
◇ Adopting advanced and reliable rotary isolation switches, it can safely enter the circuit breaker room for maintenance when the main busbar is live.
◇ The protection level of the entire cabinet is IP2X.
◇ Equipped with a reliable and fully functional mandatory mechanical locking device, it is simple and effective to meet the "five prevention" requirements.
◇ Have a reliable grounding system.
◇ There is an observation window installed on the door, which can clearly observe the working status of the components inside the cabinet.
◇ The operating mechanism adopts the JSXGN locking mechanism used in the same XGN2-12 cabinet, which is simple, reliable, convenient, and practical.
◇ The inlet and outlet cables are lower than the front of the cabinet, making it convenient for users to connect.
