High Voltage Fixed Switchgear HXGN17-12/24/40.5KV
Short Description:
Product OverviewThe XGN17-12 box type fixed AC metal enclosed switchgear (referred to as the ring main unit) has a rated voltage of 12kV. A complete set of AC high-voltage electrical equipment with a rated frequency of 50Hz is mainly used for three-phase AC loop networks, terminal distribution netwo …
Product details
Product Overview
The XGN17-12 box type fixed AC metal enclosed switchgear (referred to as the ring main unit) has a rated voltage of 12kV. A complete set of AC high-voltage electrical equipment with a rated frequency of 50Hz is mainly used for three-phase AC loop networks, terminal distribution networks, and industrial electrical equipment. It plays a role in receiving and distributing electrical energy, and is also suitable for equipment in box type substations.
Environmental Conditions for Use
◆ Surrounding air temperature: -15 ℃ ~+40 ℃ ;
◆ Altitude: 2000m and below;
◆ Humidity conditions: The daily average value shall not exceed 95%, and the daily average value of water vapor pressure shall not exceed 2.2kPa;
The monthly average value shall not exceed 90%, and the monthly average value of water vapor pressure shall not exceed 1.8kPa.
Earthquake intensity: not exceeding 8 degrees;
Places without obvious pollution such as corrosive or flammable gases.
Note: When the above normal usage conditions are exceeded, users can negotiate with our company.
