DFW American Style Cable Junction Box
Short Description:
Our company's American style cable junction boxes, with their excellent peLXormance, standardized design, and beautiful appearance, are widely used in cable engineering equipment in cable distribution network systems. They are widely recognized in various places such as major industrial parks, residential areas, densely populated urban areas, commercial centers, and high-rise buildings. It is mainly characterized by one-way door opening and horizontal multi way busbar, and has significant advantages such as small width, flexible combination, full insulation, and full sealing. According to the rated current, it can generally be divided into two types: 600A main circuit and 200A branch circuit. The 600A main circuit adopts a screw in bolt fixed connection; The 200A branch circuit adopts a plug-in connection and can be plugged and unplugged with load.
Product details
Product Overview
Our company's American style cable junction boxes, with their excellent peLXormance, standardized design, and beautiful appearance, are widely used in cable engineering equipment in cable distribution network systems. They are widely recognized in various places such as major industrial parks, residential areas, densely populated urban areas, commercial centers, and high-rise buildings. It is mainly characterized by one-way door opening and horizontal multi way busbar, and has significant advantages such as small width, flexible combination, full insulation, and full sealing. According to the rated current, it can generally be divided into two types: 600A main circuit and 200A branch circuit. The 600A main circuit adopts a screw in bolt fixed connection; The 200A branch circuit adopts a plug-in connection and can be plugged and unplugged with load.
Normal Usage Environment
Environmental temperature: maximum temperature:+40 ℃ , minimum temperature: -30 ℃
Wind speed: equivalent to 34m/s (not exceeding 700Pa)
Humidity: The average daily relative humidity should not exceed 95%, and the average monthly relative humidity should not exceed 95%
Shockproof: The horizontal acceleration shall not exceed 0 4m/s2, vertical acceleration not exceeding 0.1 5m/s2
Installation site inclination: not greater than 30 °
Installation environment: The surrounding air should not be significantly polluted by corrosive, flammable gases, water vapor, etc., and
there should be no severe vibration at the installation site
Note: When ordering this product beyond the above conditions, please consult with our company.
