DFW European Style Cable Junction Box
Short Description:
Product OverviewThe European style cable junction box is a widely used cable engineering equipment in power distribution network systems in recent years. Its main characteristics are bidirectional door opening, using docking sleeves as connecting busbars, and having significant advantages such as sm …
Product details
Product Overview
The European style cable junction box is a widely used cable engineering equipment in power distribution network systems in recent years. Its main characteristics are bidirectional door opening, using docking sleeves as connecting busbars, and having significant advantages such as small length, clear cable arrangement, and no need for large span crossing of three core cables. The cable joints used comply with the DIN47636 standard.
Generally, a bolted connection cable joint with a rated current of 630A is used.
Normal Usage Environment
Environmental temperature: maximum temperature:+40 ℃ , minimum temperature: -30 ℃
Wind speed: equivalent to 34m/s (not exceeding 700Pa)
Humidity: The average daily relative humidity should not exceed 95%, and the average monthly relative humidity should not exceed 95%
Shockproof: Horizontal acceleration not exceeding 0.4m/s2, vertical acceleration not exceeding 0.15m/s2
Installation site inclination: not greater than 3 °
Installation environment: The surrounding air should not be significantly polluted by corrosive, flammable gases, water vapor, etc., and the installation site should not have severe vibration.
When ordering this product beyond the above conditions, please negotiate with our company.
