Three Phase Dry Tpye Transformer SC(B)10/20/35kV
Short Description:
Boerstn Electric manufacture a complete range of three phase distribution transformers,Including oil-immersed type&cast resin dry-type transformer,we always designed with increased margins of safety and reliability and meet the following standard.IEC60076.
Product details
Overview
This product is widely used in areas where it is particularly suitable for use in locations where fire protection is high, such as mines, oil fields, subways, power plants, schools, hospitals,commercial centers, high-rise buildings and all Within the configuration system.
Working Conditions
◆ Installation height: no more than 3000m above sea level;
◆ Power supply voltage waveform: like sine wave;
◆ Multi-phase power supply voltage symmetry: multi-phase transformer connected to the power supply voltage should be symmetrical.
◆ Ambient temperature: maximum temperature +40C; the highest daily average temperature of +30C; the highest annual average temperature of + 20C; minimum temperature -25C(for indoor transformers).
