S11 series 33kV class oltc power transformer
Short Description:
S11 series 15/20kV Distribution Transformers refer to a static electrical appliance in a powerdistribution system that converts AC voltage and current according to the law of electromagneticinduction to transmit AC power. In some areas, power Transformers with a voltage level below 20kVare called "distribution Transformers" or "blending" for short. The installation of 'matched" places andplaces is both a substation. Distribution Transformers should be installed on the column or open floorinstallation.
Product details
Product overview:
S11 series 15/20kV Distribution Transformers refer to a static electrical appliance in a powerdistribution system that converts AC voltage and current according to the law of electromagneticinduction to transmit AC power. In some areas, power Transformers with a voltage level below 20kVare called "distribution Transformers" or "blending" for short. The installation of 'matched" places andplaces is both a substation. Distribution Transformers should be installed on the column or open floorinstallation.
Features of Products：
1.Meet or exceeds ANSI.IEC.GB.SANS.Standards
2.Safe Handling, Installation and Operation.
3. Attractive, modern appearance
4. Reasonable Structure
5.Fully-sealed
6. Higher system reliability
7. High security and reliability in operation
8. High capacity of overload and efficiency
9. Robust construction having excellent short circuit and thermal withstand capabilities10.Transformers are more efficient by reduced no-load losses and Reduced load losses
Sllseries 33kV single phase pole-mounted distribution transformer：
